Review façade design criteria and performance requirements before detailed design helps design managers, façade consultants, and contractors align targets, tests, and documentation early, avoiding rework and ensuring compliant envelope performance.
- Clarify loads, movements, and interfaces to prevent costly redesigns later.
- Set measurable thermal, air, water, fire, and acoustic targets with evidence.
- Coordinate testing plans, mock-ups, and approvals per project specifications.
- Use interactive, commentable, export features with QR code verification.
The checklist
Structural and Load Criteria
- Confirm design wind pressures and zones from the wind microclimate study; method: review report and apply zone maps to elevations; acceptance: pressures assigned to each panel; evidence: annotated elevations, signed calculation summary.
- Set serviceability deflection limits for mullions/transoms; method: preliminary frame analysis; acceptance: lateral deflection ≤ span/500 at service wind; evidence: analysis printout with load cases and sign-off.
- Verify ultimate strength with connection reactions; method: load path review and connection checks; acceptance: factor of safety ≥ specified in project documents; evidence: connection schedule with reaction table and engineer approval.
- Assess building movements (interstorey drift, creep, thermal); method: obtain structural report and expansion estimates; acceptance: jointing accommodates calculated movement + 20% allowance; evidence: movement matrix and interface sketches.
- Confirm primary structure capacity at fixing points; method: check anchor edge distances and slab/beam capacity; acceptance: reactions within allowable limits; evidence: anchor layout with structural endorsement.
Thermal, Moisture, and Air Performance
- Define target U-values and solar control (SHGC/g-value); method: align with energy model; acceptance: targets recorded per orientation/system; evidence: signed performance schedule and model extracts.
- Set façade air permeability criteria; method: reference whole-building airtightness strategy; acceptance: rate ≤ specified m³/(h·m²) at 50 Pa; evidence: design note and test method statement.
- Establish water penetration resistance levels; method: select static/dynamic test pressures; acceptance: no leakage at specified pressures and duration; evidence: laboratory test plan and acceptance table.
- Evaluate condensation risk and thermal bridges; method: 2D/3D thermal modelling; acceptance: surface temperature factor prevents mould growth; evidence: thermal report with isotherms and reviewer sign-off.
- Define drainage and weep strategy; method: section review for cavities and baffles; acceptance: positive drainage paths with ≥ 1:100 slope; evidence: annotated sections and detail references.
Fire, Acoustic, and Safety Requirements
- Confirm material reaction-to-fire and any required fire resistance; method: review fire strategy; acceptance: classifications meet project specifications and authority requirements; evidence: product data sheets and fire engineer confirmation.
- Define cavity barrier and fire-stopping locations; method: interface matrix and compartment line overlays; acceptance: continuous barriers at all required lines; evidence: marked drawings and responsibility matrix.
- Set acoustic performance targets; method: consult acoustic report; acceptance: Rw/DnT,w per space types documented; evidence: acoustic schedule and calculation summary.
- Confirm impact safety and fall protection requirements; method: review glazing thickness and fixity; acceptance: line load and impact resistance satisfied; evidence: calculations and product certification.
- Agree maintenance and cleaning strategy; method: BMU/anchor layout review; acceptance: safe access coverage with rated anchors; evidence: access plan, load checks, and O&M outline.
Materials, Durability, and Interfaces
- Select materials for corrosion resistance and exposure; method: environmental category assessment; acceptance: finishes and alloys match exposure class; evidence: datasheets and draft warranties.
- Verify sealant and gasket compatibility; method: supplier compatibility letters or lab screening; acceptance: no softening, swelling, or staining; evidence: compatibility statements and batch records.
- Set coating and finish criteria; method: sample review and lab tests; acceptance: colour ΔE ≤ 2.0 and gloss as specified; evidence: test reports and approved tagged samples.
- Define fastener/anchor types and protection; method: preliminary pull-out/torque trials; acceptance: resistance ≥ design load × safety factor; evidence: trial records and specification schedule.
- Set interface tolerances and adjustability; method: tolerance stack-up analysis; acceptance: accommodate ±10 mm floor edge variance; evidence: tolerance table and interface sketches.
Testing, Documentation, and Compliance
- Plan performance mock-up scope; method: mock-up matrix covering corners, spandrels, and interfaces; acceptance: all critical details included; evidence: approved ITP and signatures.
- Agree lab and on-site test programs; method: select methods per approved project specifications and authority requirements; acceptance: air, water, structural, impact tests scheduled; evidence: test program and QA plan with dates.
Preview the printable checklist
Preview page one below. Open the image or download the PDF for all pages.
At a glance
- Establish a clear façade basis-of-design by agreeing wind loads, building movements, support reactions, and interface tolerances before detailing begins. This reduces structural clashes, ensures anchors and brackets are right-sized, and provides traceable acceptance criteria that guide engineers, suppliers, and reviewers through the following design stages.
- Translate project energy goals into façade performance targets, including U-values, surface temperature factors to prevent condensation, air permeability at defined pressures, and watertightness at static and dynamic conditions. Document calculation methods, test pressures, and evidence requirements so laboratory and field verification aligns with the specification and authority expectations.
- De-risk life-safety and comfort outcomes by confirming reaction-to-fire requirements, cavity barriers at compartment lines, acoustic reductions, impact safety, and maintenance access strategies. Record product classification data, acoustic schedules, and barrier continuity diagrams, then link them to testing and inspection plans to ensure continuous compliance across build stages.
- Interactive online checklist with tick, comment, and export features secured by QR code.
How to use this interactive pre-design façade review checklist
- Preparation: Gather wind studies, structural movement data, energy model outputs, fire and acoustic reports, preliminary layouts, and product data. Ensure stakeholders (architect, structural, MEP, fire, façade) can access the platform. Wear appropriate PPE if performing site verifications.
- Set targets: Enter project-specific performance targets (loads, deflection, U-values, air/water, fire, acoustic) in the checklist fields. Attach supporting reports and define acceptance criteria per approved project specifications and authority requirements.
- Using the Interactive Checklist: Switch to interactive mode, tick items as you verify, add time-stamped comments, assign actions to owners with due dates, and attach photos, calcs, or model snapshots for evidence.
- Coordinate: Mention and resolve clashes directly in comments (e.g., anchor edge distance, barrier continuity). Update items’ status and reassign until acceptance evidence is complete and approved.
- Export: Generate an export as PDF/Excel including tick status, comments, attachments, and issue log. The file is sealed with a QR code for authenticity and quick access to the live record.
- Sign-Off: Capture digital signatures from responsible leads (architect, façade engineer, contractor). Distribute the signed export to stakeholders and archive within the project’s CDE with QR-linked traceability.
Lock in structural and movement assumptions early
Early agreement on wind pressures, support reactions, and building movements prevents late-stage redesigns and anchor changes. Start by mapping wind study zones on elevations, then run preliminary frame analyses to set serviceability limits. Combine structural reports for interstorey drift, creep, and thermal expansion to produce a movement matrix. Align fixings with primary structure capacity, checking edge distances and reinforcement. Capture all assumptions, limits of validity, and load combinations in a short basis-of-design document. On one tower project, clarifying span/deflection limits (H/500) and bracket adjustability avoided a mid-design mullion change and two months of delay. Acceptance cues include signed calculation summaries, annotated elevations, and a tolerance stack that demonstrates adjustability. The objective is not final detailing, but a robust foundation that every discipline can trust when pushing into detailed design and procurement.
- Apply wind zones directly onto façade elevations.
- Summarize deflection limits and movement allowances.
- Confirm anchor reactions versus structural allowances.
- Produce a concise basis-of-design record.
- Secure sign-offs before detailed design starts.
Define thermal, air, and water performance with evidence
Translate project energy goals into façade performance targets before sketching details. Record U-values and solar control by orientation and system type, then model thermal bridges to ensure interior surface temperatures stay above mould risk thresholds. Set air permeability criteria consistent with whole-building airtightness and agree test pressures for static and dynamic watertightness. In one mock-up, a missing baffle allowed concealed leakage under dynamic pressure; predefining drainage paths and inspection points would have prevented retesting. Acceptance cues include signed energy model extracts, thermal simulation reports with isotherms, a watertightness test matrix, and a clear air leakage target with test methods. Coordination at this stage lets designers pick gasket profiles, drain slot geometry, and sealant types that hit targets without overdesign.
- List U-values and g-values by elevation.
- Model critical thermal bridges and corners.
- Set air and water test pressures early.
- Show drainage paths in section details.
- Attach simulation reports and approvals.
Protect life safety, comfort, and maintainability
Before details are fixed, confirm fire strategy interfaces, acoustic targets, impact safety, and maintenance access provisions. Identify cavity barrier lines at compartment boundaries and select compliant barrier types. Agree material reaction-to-fire classifications and any required fire resistance. Capture acoustic performance per space type and façade system, then check glazing, fixity, and line loads for impact safety and fall protection. Define access coverage, anchor capacities, and cleaning methods to avoid retrofitted hardware later. A recent review flagged missing barriers at a transfer floor; resolving it now prevented costly rework during construction. Acceptance cues include a barrier continuity overlay, product classification data, acoustic schedules, and an access plan with load checks. Tie these into a testing and inspection plan to make compliance visible and auditable.
- Overlay barriers on fire compartment drawings.
- Record acoustic targets by room and system.
- Validate glazing impact and line load capacity.
- Plan safe access coverage and anchors.
- Link requirements to test and inspection plans.
